Tungsten Carbide Combined Hammer Blade

Tungsten carbide combined hammer blade

(Tungsten carbide overlay welding and fusion welding hammer blade)

Technical features:

1. Shape: Single headed single hole type, double headed double hole type

2. Size: Various sizes, customized

3. Material: High quality wear-resistant steel, wear-resistant welding wire, tungsten carbide particles

4. Hardness:

HRC70-75 (hard alloy layer)

Hardface of weld overlay - HRC 58-68 (wear-resistant layer)

Hammer Body - HRC 38-45 and Stress Relief

Surrounding the hole: HRC38-45 (hardness can be customized according to customer requirements)

HMT’hammer blade PK market’ hammer blade

1. Combination welding technology. Other similar products in the market cannot achieve it.

2. Both processes incorporate tungsten carbide particles. Other similar products in the market cannot achieve it.

Technical features:

1. Combination 1: The top of the hammers adopts overlay welding technology, and the two sides adopt fusion welding technology.

2. Combination 2: The top of the hammer piece adopts fusion welding technology, and the two sides adopt olverlay welding technology.

3. Perfectly combining wear resistance and impact resistance for a longer service life.

4. Perfectly combining the advantages of tungsten carbide overlay welding and tungsten carbide fusion welding hammers, the performance is better.

5. Design directional combination hammers according to different crushed materials. The application of two combinations forms complementary advantages.

Product advantages:

1. High hardness: The hardness of the wear-resistant layer of the tungsten carbdide overlay welding combination hammers is usually above HRC70-75, which can maintain good wear resistance in harsh environments such as high temperature, high pressure, and high speed.

2. High toughness: It not only has high hardness, but also has a certain degree of toughness, making it have good impact resistance and vibration resistance.

3. Good wear resistance: The tungsten carbide combination hammer blade has excellent wear resistance, which can extend the service life of the equipment and reduce maintenance costs.

4. Good corrosion resistance: The tungsten carbide combination hammer blade has good corrosion resistance and strong corrosion resistance.
